5t Flat Webbing Sling
5t Flat Webbing Sling
- Capacity: 5t
Strong and durable, our 5 tonne flat webbing slings are constructed from premium-grade, high tenacity polyester yarn, and feature standard folded eyes, complete with eye wear padding for superior eye protection. Each sling is manufactured to the highest standards and is individually proof tested, serial numbered, tagged and complete with test certificate.
- Australian Standard: AS1353.1
Features
Industries
Documents
Features
- 2 ply webbing
- Unique serial number
- Proof tested to 2 x W.L.L.
- Break load limit is 8 x the indicated load
Industries
- Civil
- Construction
- Cranes
- Engineering
- Infrastructure
- Lifts/Elevators
- Manufacturing
- Marine
- Ports
Documents
Specifications
Dimensions
Specifications
| PRODUCT CODE | W.L.L. | WIDTH | LENGTH | NET WEIGHT |
|---|---|---|---|---|
| AL910515 | 5.0t | 150mm | 1.5m | 1.74kg |
| AL910520 | 5.0t | 150mm | 2.0m | 2.30kg |
| AL910530 | 5.0t | 150mm | 3.0m | 3.50kg |
| AL910540 | 5.0t | 150mm | 4.0m | 4.50kg |
| AL910550 | 5.0t | 150mm | 5.0m | 6.00kg |
| AL910560 | 5.0t | 150mm | 6.0m | 19.00kg |
| AL910570 | 5.0t | 150mm | 7.0m | 22.10kg |
| AL910580 | 5.0t | 150mm | 8.0m | 25.30kg |
| AL910590 | 5.0t | 150mm | 9.0m | 28.49kg |
| AL910591 | 5.0t | 150mm | 10.0m | 31.60kg |
