Foot Controlled Hydraulic Air Pumps
Foot Controlled Hydraulic Air Pumps
- Brand: Boss Hydraulics
- Capacity: 10,000 psi / 700 Bar
Reliable, efficient and easy to operate, this portable foot controlled hydraulic air pump uses compressed air to generate hydraulic pressure for the powering of hydraulic tools and equipment, making it ideal for various industrial applications.
Features
Industries
Documents
Features
- Internal relief valve
- Aluminium reservoir
- Single and double acting models available
Industries
- Automotive
- Construction
- Engineering
- Infrastructure
- Mining/Oil/Gas
Documents
Specifications
Dimensions
Specifications
| PRODUCT CODE | VALVE TYPE | OIL DELIVERY – 0 BAR | OIL DELIVERY – 700 BAR | INPUT AIR PRESSURE | AIR CONSUMPTION | OIL CAPACITY | USABLE OIL | NET WEIGHT |
|---|---|---|---|---|---|---|---|---|
| BHPA010 | Single Acting | 700cc/min | 100cc/min | 7-10 bar | 9cfm | 850cc | 750cc | 5.4kg |
| BHPA019 | Single Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 1600cc | 1300cc | 7.3kg |
| BHPAR019 | Single Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 1600cc | 1300cc | 8.5kg |
| BHPA019-2 | Single Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 2600cc | 2000cc | 9.1kg |
| BHPA019-3 | Single Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 3000cc | 2500cc | 9.3kg |
| BHPA019-8 | Single Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 8000cc | 7200cc | 14.0kg |
| BHPAD019 | Double Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 1600cc | 1300cc | 9.1kg |
| BHPAD019-3 | Double Acting | 1250cc/min | 193cc/min | 7-10 bar | 9cfm | 3000cc | 2500cc | 12.0kg |
| BHPAD019-8 | Double Acting | 1250cc/min | 193cc/min | 7-10 bar | 9 cfm | 8000cc | 7200cc | 17.0kg |
Dimensions
| PRODUCT CODE | A | B | C | D | E | F | G |
|---|---|---|---|---|---|---|---|
| BHPA010 | 423mm | 170mm | 70mm | 399mm | 160mm | 47mm | 59mm |
| BHPA019 | 242mm | 129mm | 90mm | 257mm | 151mm | 113mm | 205mm |
| BHPAR019 | 242mm | 129mm | 90mm | 257mm | 151mm | 113mm | 205mm |
| BHPA019-2 | 279mm | 144mm | 91mm | 304mm | 159mm | 120mm | 208mm |
| BHPA019-3 | 309mm | 160mm | 98mm | 325mm | 151mm | 114mm | 245mm |
| BHPA019-8 | 312mm | 312mm | 90mm | 312mm | 184mm | 146mm | 238mm |
| BHPAD019 | 242mm | 129mm | 98mm | 304mm | 188mm | 113mm | 205mm |
| BHPAD019-3 | 309mm | 160mm | 98mm | 343mm | 189mm | 114mm | 245mm |
| BHPAD019-8 | 312mm | 312mm | 98mm | 312mm | 221mm | 146mm | 278mm |
