18×7+FC B2070 Black Wire Rope
18×7+FC B2070 Black Wire Rope
- Brand: Austlift
Our 18x7 non-rotating wire ropes have a non-spin characteristic suitable for lifting rope on cranes. Available by the metre or reel.
- Australian Standard: AS3569
Features
Industries
Documents
Features
- Non-rotating and non-spin
- Manufactured from G2070 galvanised steel, finished in black
Industries
- Civil
- Construction
- Cranes
- Engineering
- Entertainment
- Infrastructure
- Lifts/Elevators
- Marine
- Ports
Documents
Specifications
Dimensions
Specifications
| PRODUCT CODE | SIZE | GRADE | MBS | LENGTH | NET WEIGHT |
|---|---|---|---|---|---|
| AL887065 | 6mm | 2070 | 23.7kN | 500m | 69.0kg |
| AL887060 | 6mm | 2070 | 23.7kN | 1000m | 138.0kg |
| AL887085 | 8mm | 2070 | 42.1kN | 500m | 122.5kg |
| AL887095 | 9mm | 2070 | 53.4kN | 500m | 155.0kg |
| AL887105 | 10mm | 2070 | 66.1kN | 500m | 191.5kg |
| AL887115 | 11mm | 2070 | 79.8kN | 500m | 231.5kg |
| AL887125 | 12mm | 2070 | 95.0kN | 500m | 275.5kg |
| AL887135 | 13mm | 2070 | 111.0kN | 500m | 328.0kg |
| AL887145 | 14mm | 2070 | 130.0kN | 500m | 375.0kg |
| AL887165 | 16mm | 2070 | 168.0kN | 500m | 490.0kg |
| AL887185 | 18mm | 2070 | 214.0kN | 500m | 620.0kg |
| AL887195 | 19mm | 2070 | 238.5kN | 500m | 650.0kg |
