6×19 FC G1570 Wire Rope
6×19 FC G1570 Wire Rope
- Brand: Austlift
Our 6x19 fibre core galvanised wire ropes have a flexible characteristic and are suitable for engineering, winching, pulling, marine, slings and general purpose uses wherever rope is required for the application. Available by the metre or reel.
- Australian Standard: AS3569
Features
Industries
Documents
Features
- Fatigue resistant
- Fibre core centre
- Metal fill factor 47.38%
- Manufactured from Grade 1570 galvanised steel
Industries
- Civil
- Construction
- Cranes
- Engineering
- Entertainment
- Infrastructure
- Lifts/Elevators
- Marine
- Ports
Documents
Specifications
Dimensions
Specifications
| PRODUCT CODE | SIZE | GRADE | MBS | LENGTH | NET WEIGHT |
|---|---|---|---|---|---|
| AL869030 | 3.0mm | 1570 | 4.26kN | 1000m | 31.0kg |
| AL869035 | 3.5mm | 1570 | 5.80kN | 1000m | 42.0kg |
| AL869040 | 4.0mm | 1570 | 7.70kN | 1000m | 55.0kg |
| AL869050 | 5.0mm | 1570 | 12.00kN | 1000m | 86.5kg |
| AL869060 | 6.0mm | 1570 | 17.60kN | 1000m | 124.0kg |
| AL869062 | 6.0mm | 1570 | 17.60kN | 250m | 31.0kg |
| AL869080 | 8.0mm | 1570 | 30.90kN | 1000m | 221.0kg |
| AL869090 | 9.0mm | 1570 | 39.10kN | 1000m | 280.0kg |
| AL869095 | 9.0mm | 1570 | 39.10kN | 500m | 140.0kg |
